Melia LED ME2

Melia LED ME2 - LS151LED

A high-performance wall-mount luminaire available in brass or powder-coated housing

Configure this product Features Specifications

Product Overview

Designed and constructed for performance, the Wall Mount LS151LED Melia provides diffuse illumination in either a brass or powder-coated aluminum housing. This luminaire features new Lumascape d5 driver technology for advanced dimming and control options.

THIS LUMINAIRE IS ONLY AVAILABLE IN NORTH AMERICA

Features

Lumen Output 220lm Power Consumption 3W Control Protocol PWM (0-10V, DMX) IP Rating IP67 Compliance

Color Options Warm White

Warm White

Cool White

Blue (470 nm)

Data Sheet

Specifications

Downloads

Data Sheet Install Guide

DXF Files LS151LED ZIP (26.52 KB) LS151LED - IES Files.zip ZIP (19.06 KB)

Technology

Product Configurator

LS151LED _ _ _ _

Login to view pricing

Reset to Default Clear Selected Add

Customise Melia LED ME2 below

Light Engine

Required

3 W (3)

Light Source

Required

Static White (D7)

Static White (D7)

2,700 K (80 CRI, 3 SDCM)

Static White (H6)

Static White (H6)

3,000 K (80 CRI, 3 SDCM)

Static White (W4)

Static White (W4)

4,000 K (80 CRI, 3 SDCM)

Input Voltage

Required

12 to 15 Vac, 60 Hz or 12 to 24 Vdc (23)

PWM Dimmable Driver

Finish

Required

Black (BL)

Black powder coat

Anodic Silver (SL)

Anodic Silver (SL)

Anodic silver powder coat

Polished Brass (PB)

Polished Brass (PB)

Custom RAL (CC)

Custom RAL (CC)

A one-off custom colour setup fee applies. Click on 'More Info' button to add to your enquiry. Contact Lumascape for volume discount on set-up fee.

More info

Accessories

Accessories

Black Hood (LS603-BL)

Powder coated hood for LS151LED

Anodic Silver Hood (LS603-SL)

Power coated hood for LS151LED

Hood Custom RAL Colour (LS603-CC)

Powder coated hood for LS151LED - custom RAL

Copper Hood (G603-CU)

Polished copper hood for G431-LED
